• IC-250
    Voltage Single Phase 110 V
    Pump Capacity 6m3 / hr(0.5HP) BUSCH
    machine size 560 x 380 x 510H(mm)
    Vacuum Chamber 385 x 270 x 120H(mm)
    sealing bar length 250mm x 1
    NW / GW 42kg
    machine material #304 stainless
  • IC-330
    Voltage 1PH/110Vor220V 50Hz/60Hz
    Power 0.37kw
    Pump Capacity 6m3/hr (0.5HP)BUSCH
    machine size 580 x 450 x 550H (mm)
    Vacuum Chamber 410 x 350 x 160H (mm)
    sealing bar length 310mm x 1
    NW / GW 65kg / 83kg
    machine material #304 stainless
    Case Size(L*W*H)
  • IC-330-45
    Voltage single phase 110V or phase 220V
    Power 0.37kw
    Pump Capacity 8m3/hr or 18m3/hr
    machine size 760 x 450 x 510H(mm)
    Vacuum Chamber 540 x 350 x 120H(mm)
    sealing bar length 330mm x 2 sealing bars Each of the front and back
    NW / GW 68kg
    machine material #304 stainless
    Case Size(L*W*H)
  • IC-360B
    Voltage 0.75PH/220V 50Hz/60Hz
    Power 0.6kw
    Pump Capacity 18m3/hr (0.75HP)BUSCH
    machine size 640 x 480 x 520H (mm)
    Vacuum Chamber 460 x 380 x 120H (mm)
    sealing bar length 360mm x 2
    NW / GW 70kg / 90kg
    machine material #304 stainless
    Case Size(L*W*H) x x (mm)
  • IC-602
    Voltage 1PH / 220V 50Hz / 60Hz
    Power 0.75kw
    Pump Capacity 24m3/hr(1 HP)BUSCH
    machine size 680 x 550 x 540H(mm)
    Vacuum Chamber 480 x 450 x 140H(mm)
    sealing bar length (1)420mm x 1
    (2)420mm x 2
    NW / GW 90kg / 110kg
    machine material #304 stainless
    Case Size(L*W*H) 780 x 650 x 790(mm)
  • IC-612
    Voltage 1PH / 220V 50Hz / 60Hz
    Power 0.75kw
    Pump Capacity 24m3/hr(1HP)BUSCH
    machine size 680 x 570 x 900H(mm)
    Vacuum Chamber 480 x 450 x 140H(mm)
    sealing bar length (1)420mm x 1
    (2)420mm x 2
    NW / GW 95kg / 115kg
    machine material #304 stainless
    Case Size(L*W*H) 780 x 650 x 1150(mm)
  • IC-612-24
    Voltage 1PH / 220V 50Hz / 60Hz
    Power 0.75kw
    Pump Capacity 24m3/hr (1HP)BUSCH
    machine size 670 x 570 x 900H(mm)
    Vacuum Chamber 480 x 450 x 240H(mm)
    sealing bar length 420mm x 2
    NW / GW 100kg / 120kg
    machine material #304 stainless
    Case Size(L*W*H) 780 x 650 x 1150(mm)(0.58CBM)
  • IC-500
    Voltage 1PH / 220V 50Hz / 60Hz
    Power 0.75kw
    Pump Capacity 24m3/hr (1HP)BUSCH
    machine size 720 x 650 x 910H(mm)
    Vacuum Chamber 530 x 530 x 140H(mm)
    sealing bar length 500mm x 2
    NW / GW 105kg
    machine material #304 stainless
    Case Size(L*W*H)
  • IC-520
    Voltage 1PH / 220V 50Hz / 60Hz
    Power 0.75kw
    Pump Capacity 24m3/hr (1HP)BUSCH
    machine size 790 x 670 x 910H(mm)
    Vacuum Chamber 600 x 550 x 140H(mm)
    sealing bar length 520mm x 2
    NW / GW 105kg
    machine material #304 stainless
    Case Size(L*W*H)
  • IC-712
    Voltage 1PH / 220V 50Hz / 60Hz
    Power 0.75kw
    Pump Capacity 24m3/hr(1HP)BUSCH
    machine size 680 x 930 x 920H(mm)
    Vacuum Chamber 470 x 780 x 140H(mm)
    sealing bar length (1)450mm x 2 / 650mm x 1
    (2)760mm x 2
    (3)450mm x1 / 690mm x 2
    NW / GW 165kg / 195kg
    machine material #304 stainless
    Case Size(L*W*H) 780 x 1030 x 1170(mm)
  • IC-713
    Voltage 1PH / 220V 50Hz / 60Hz
    3PH / 220V 50Hz / 60Hz
    Power 0.75kw
    Pump Capacity 24m3/hr(1HP)
    40m3/hr(2HP)
    machine size 680 x 930 x 920H(mm)
    Vacuum Chamber 470 x 780 x 260H(mm)
    sealing bar length 760mm x 2
    NW / GW 185kg / 215kg
    machine material #304 stainless
    Case Size(L*W*H) 780 x 1030 x 1170(mm)
  • IC-623
    Voltage 3PH / 220V or 380V 50Hz / 60Hz
    Power 1.2kw
    Pump Capacity 40m3/hr(2HP)BUSCH
    machine size 760 x 930 x 1060H(mm)
    Vacuum Chamber 580 x 830 x 160H(mm)
    sealing bar length (1)800mm x 2
    (2)520mm x 2
    NW / GW 250kg / 290kg
    machine material #304 stainless
    Case Size(L*W*H) 800 x 1000 x 1310(mm)
  • IC-850
    Voltage 3PH / 220V or 380V
    Power 3kw
    Pump Capacity 100m3/hr(4HP)BUSCH
    machine size 850 x 960 x 1100H(mm)
    Vacuum Chamber 730 x 890 x 220H(mm)
    sealing bar length (1)850mm x 2
    (2)650mm x 2
    NW / GW 280kg / 320kg
    machine material 304 stainless
    Case Size(L*W*H) 950 x 1060 x 1350(mm)
  • IC-850A(Pneumatic automatic swing lid)
    Voltage 3PH / 220V or 380V
    Power 3kw
    Pump Capacity 100m3/hr(4HP)BUSCH
    machine size 850 x 960 x 1100H(mm)
    Vacuum Chamber 730 x 890 x 220H(mm)
    sealing bar length (1)850mm x 2
    (2)650mm x 2
    NW / GW 280kg / 320kg
    machine material 304 stainless
    Case Size(L*W*H) 950 x 1060 x 1350(mm)
  • IC-900
    Voltage 3PH / 220V
    Power 3kw
    Pump Capacity 100m3/hr (4HP)BUSCH
    machine size 790 x 1000 x 1060H(mm)
    Vacuum Chamber 670 x 930 x 210H(mm)
    sealing bar length (1)900mm x 2
    (2)600mm x 2
    NW / GW 280kg / 320kg
    machine material #304 stainless
    Case Size(L*W*H) 960 x 1150 x 1340(mm)
  • IC-900W
    Voltage 220V/380V
    BUSCH Pump Capacity 100m3/hr
    Machine Size 1000 x 700 x 1060H(mm)
    Vacuum Chamber 930 x 580 x 160H(mm)
    Groove Size 760 x 400 x 150H(mm)
    Sealing Length 900mm x 2
    NW/GW 280kg/320kg
    machine material #304 stainless
    Case Size(L*W*H) 1150 x 890 x 1340H(mm)
  • IC-1000
    Voltage 3PH / 220V
    Power 3kw
    Pump Capacity 100m3/hr (4HP)BUSCH
    machine size 840 x 1170 x 1060H(mm)
    Vacuum Chamber 720 x 1100 x 210H(mm)
    sealing bar length (1)1000mm x 2
    (2)650mm x 2
    NW / GW 300kg / 340kg
    machine material #304 stainless
    Case Size(L*W*H) x x (mm)
  • IC-1100A(Pneumatic automatic swing lid)
    Voltage 3PH / 220V or 380V 50Hz / 60Hz
    Power 3kw
    Pump Capacity 100m3/hr (4HP)BUSCH
    machine size 840 x 1270 x 1060H(mm)
    Vacuum Chamber 720 x 1200 x 210H(mm)
    sealing bar length (1)1100mm x 2
    (2)650mm x 2
    NW / GW 320kg / 360kg
    machine material #304 stainless
    Case Size(L*W*H) x x (mm)
  • IC-1300LA
    Voltage 3PH / 220V or 380V 50Hz / 60Hz
    Pump Capacity 100m3/hr(4HP )BUSCH
    machine size 840 x 1470 x 1060H(mm)
    Vacuum Chamber 720 x 1400 x 250H(mm)
    sealing bar length 650mm x 1+1200mm x 1
    NW / GW 380kg / 420kg
    machine material #304 stainless
  • IC-1620
    Voltage 3PH / 220V or 380V 50Hz / 60Hz
    Power 2.2kw
    Pump Capacity 63m3/hr(3HP )BUSCH
    machine size 630 x 1620 x 920H(mm)
    Vacuum Chamber 470 x 1520 x 200H(mm)
    sealing bar length (1)450mm x 2
    (2)1450mm x 2
    NW / GW 320kg / 370kg
    machine material #304 stainless
    Case Size(L*W*H) 730 x 1720 x 1170(mm)
  • IC-624
    Voltage 3PH / 220V or 380V 50Hz / 60Hz
    Power 2.2kw
    Pump Capacity 63m3/hr(3HP)BUSCH
    machine size 700 x 1800 x 1060H(mm)
    Vacuum Chamber 580 x 830 x 160H(mm) x 2
    sealing bar length 800mm x 4
    NW / GW 490kg / 550kg
    machine material #304 stainless
    Case Size(L*W*H) 800 x 1900 x 1310(mm)
  • IC-634
    Voltage 3PH / 220V or 380V 50Hz / 60Hz
    Power 3kw
    Pump Capacity 100m3/hr(4HP)BUSCH
    machine size 790 x 1820 x 1000H(mm)
    Vacuum Chamber 600 x 890 x 200H(mm)
    sealing bar length 720mm x 4
    NW / GW 490kg / 550kg
    machine material 304 stainless
    Case Size(L*W*H) 890 x 1920 x 1250(mm)
  • IC-634-62
    Voltage 3PH / 220V or 380V 50Hz / 60Hz
    Pump Capacity 100m3/hr(4HP)BUSCH
    machine size 920 x 1820 x 1000H(mm)
    Vacuum Chamber 730 x 890 x 200H(mm)
    sealing bar length 720mm x 4
    NW / GW 540kg / 580kg
    machine material 304 stainless
  • IC-635
    Voltage 3PH / 220V or 380V 50Hz / 60Hz
    Power 3kw
    Pump Capacity 100m3/hr(4HP)BUSCH
    machine size 810 x 1940 x 1000H(mm)
    Vacuum Chamber 640 x 980 x 200H(mm)
    sealing bar length 800mm x 4
    NW / GW 530kg / 570kg
    machine material #304 stainless
    Case Size(L*W*H) 910 x 2040 x 1250(mm)
  • IC-635U
    Voltage 3PH / 220V or 380V 50Hz / 60Hz
    Power 3kw
    Pump Capacity 100m3/hr(4HP)BUSCH
    machine size 810 x 1940 x 1000H(mm)
    Vacuum Chamber 640 x 980 x 200H(mm)
    sealing bar length 800mm x 4+450mm x 2
    NW / GW 530kg / 570kg
    machine material #304 stainless
    Case Size(L*W*H) 910 x 2040 x 1250(mm)
  • AU2-850
    Voltage 3PH / 220V or 380V 50Hz / 60Hz
    Power 5.6kw
    Pump Capacity 202m3/ hr (7.5HP)BUSCH
    machine size 900 x 2060 x 1120H(mm)
    Vacuum Chamber 720 x 1040 x 220H(mm)
    sealing bar length 850mm x 4
    NW / GW 620kg / 680kg
    machine material #304 stainless
    Case Size(L*W*H) 1000 x 2160 x 1450(mm)
  • IC-636
    Voltage 3PH / 220V or 380V 50Hz / 60Hz
    Power 5.6kw
    Pump Capacity 202m3/hr(7.5HP)BUSCH
    machine size 1160 x 2100 x 1100H(mm)
    Vacuum Chamber 950 x 1060 x 300H(mm)
    sealing bar length 880mm x 4
    NW / GW 680kg / 756kg
    machine material #304 stainless
    Case Size(L*W*H) 1260 x 2200 x 1350 (mm)
  • IC-636U
    Voltage 3PH/220Vor380V/50Hz/60Hz
    Power 5.6kw
    Pump Capacity 202m3/hr(7.5HP)
    machine size 1160 x 2100 x 1100H(mm)
    Vacuum Chamber 950 x 1060 x 250H(mm)-1
    950 x 1060 x 300H(mm)-2
    sealing bar length 880mm x 4 /780mm x 2
    machine material #304 stainless
    Case Size(L*W*H) 1260 x 2200 x 1350(mm)
    NW / GW 680kg / 756kg
  • IC-637-72
    Voltage 3PH / 220V or 380V 50Hz / 60Hz
    Pump Capacity 202m3/hr(7.5HP)BUSCH
    machine size 1060 x 2400 x 1100H(mm)
    Vacuum Chamber 810 x 1180 x 250H(mm)
    sealing bar length 1000mm x 4
    NW / GW 680/756kg
    machine material #304 stainless
  • IC-637
    Voltage 3PH / 220V or 380V 50Hz / 60Hz
    Power 7.4kw
    Pump Capacity 302m3/hr(10HP)BUSCH
    machine size 1240 x 2400 x 1180H(mm)
    Vacuum Chamber 990 x 1180 x 300H(mm)
    sealing bar length 1000mm x 4
    NW / GW 730kg
    machine material #304 stainless
    Case Size(L*W*H) 2520 x 1320 x 1360(mm)
  • IC-638
    Voltage 3PH / 220V or 380V 50Hz / 60Hz
    Power 7.4kw
    Pump Capacity 300m3/hr
    machine size 2540 x 1160 x 1110H(mm)
    Vacuum Chamber 1280 x 950 x 300H(mm)
    sealing bar length 1100mm x 4
    NW / GW 780kg
    machine material #304 stainless
    Case Size(L*W*H) 1270 x 2700 x 1360(mm)
  • IC-635A(Pneumatic automatic swing lid)
    Voltage 3PH / 220V or 380V 50Hz / 60Hz
    Power 3kw
    Pump Capacity 100m3/hr(4HP)BUSCH
    machine size 810 x 1940 x 1000H(mm)
    Vacuum Chamber 640 x 980 x 200H(mm)
    sealing bar length 800mm x 4
    NW / GW 530kg / 570kg
    machine material #304 stainless
    Case Size(L*W*H) 910 x 2040 x 1250(mm)
  • IC-636A(Pneumatic automatic swing lid)
    Voltage 3PH / 220V or 380V 50Hz / 60Hz
    Power 5.6kw
    Pump Capacity 202m3/hr(7.5HP)BUSCH
    machine size 1160 x 2100 x 1100H(mm)
    Vacuum Chamber 950 x 1060 x 300H(mm)
    sealing bar length 880mm x 4
    NW / GW 680kg / 756kg
    machine material #304 stainless
    Case Size(L*W*H) 1260 x 2200 x 1350 (mm)
  • AU2-850A(Pneumatic automatic swing lid)
    Voltage 3PH / 220V or 380V 50Hz / 60Hz
    Power 5.6kw
    Pump Capacity 202m3/hr(7.5HP)BUSCH
    machine size 900 x 2060 x 1120H(mm)
    Vacuum Chamber 720 x 1040 x 220H(mm)
    sealing bar length 850mm x 4
    NW / GW 620kg / 680kg
    machine material #304 stainless
    Case Size(L*W*H) 1000 x 2160 x 1450(mm)
  • AU2850-75A
    Voltage 3PH / 220V or 380V 50Hz / 60Hz
    Power 5.6kw
    Pump Capacity 202m3/hr(7.5HP)BUSCH
    machine size 1050 x 2060 x 1120H(mm)
    Vacuum Chamber 870 x 1040 x 220H(mm)
    sealing bar length 850mm x 4
    NW / GW 640kg / 700kg
    machine material #304 stainless
  • IC-637-72A
    Voltage 3PH / 220V or 380V 50Hz / 60Hz
    Pump Capacity 202m3/hr(7.5HP)BUSCH
    machine size 1060 x 2400 x 1100H(mm)
    Vacuum Chamber 810 x 1180 x 250H(mm)
    sealing bar length 1000mm x 4
    NW / GW 680/756kg
    machine material #304 stainless
  • IC-641
    Voltage 220V or 380V / 50Hz / 60Hz
    Power 3kw or 5.6kw
    Pump Capacity 100m3 / hr or 202m3 / hr
    machine size 1960 x 1660 x 1310H(mm)
    distance between sealing bar 400mm
    Chamber height 100mm
    sealing bar length 1050mm
    NW 600kg
    machine material #304 stainless
    Case Size(L*W*H) 2120 × 1600 × 1610(mm)
  • IC-613
    Voltage 3PH / 220V
    Power 1.2kw
    Pump Capacity 40m3/hr(2HP)BUSCH
    machine size 810 x 850 x 910H(mm)
    Vacuum Chamber 570 x 800 x 140H(mm)
    sealing bar length (1)780mm x 2
    (2)540mm x 2
    NW / GW 220kg / 255kg
    machine material #304 stainless
    Case Size(L*W*H) 910 x 980 x 1140(mm)

  • TOUCH CONTROL PANEL：

    45 memories programs With package number indication With signal display of vacuum oil replacement User- friendly operation, independent displayed screen, easy reading, simple operation



    Options

    Gas flush device Special percentage pressure setting for electronics factory sealing + bag cut ( two-stage heating) High pressure seal Filter for water / dust 8mm / 10mm wide sealing wire soft air
GO TOP
